Certificates
Certificatesoverview
Certificatenumber |
Designation |
Type |
Producer |
---|---|---|---|
20200101 |
Gas-insulated metal-enclosed surge arrester for GIS ELK-3/420kV |
3Z32M |
Hitachi ABB Power Grids |
20200201 |
Gas insulated, metal enclosed current transformer for ELK-3, 420 kV |
CN3 |
PFIFFNER Instrument Transformers Ltd. |
20200301 |
GIS Cable Connection / ELK-14, 300 kV |
HK14 |
ABB Power Grids Czech Republic |
20200302 |
GIS Transformer Connection |
HT14 |
ABB Power Grids Switzerland |
20200303 |
GIS Components and connecting elements |
V.14 |
ABB Power Grids Switzerland |
20200501 |
Three-phase gas-insulated, metal-enclosed circuit-breaker |
SP14 |
ABB Power Grids Switzerland |
20200502 |
Three-phase gas-insulated, metal-enclosed circuit-breaker |
SP14 |
ABB Contracting Company Ltd |
20200503 |
Three-phase gas-insulated, metal-enclosed circuit-breaker |
SP14 |
Hitachi Energy |
ZP-2020-004-01 |
Gas-insulated metal-enclosed combined disconnector / earthing switch |
ELK-14, 300 kV, TK14 |
Hitachi Energy Switzerland Ltd |
ZP-2020-005-04 |
Three-phase SF6 gas-insulated, metal-enclosed circuit-breaker |
SP14 |
Hitachi Energy Switzerland LTD |
ZP-2021-002-01 |
Gas-insulated metal-enclosed earthing switch with short-circuit making current capability |
ELK-14, 300 kV, EB14 |
Hitachi Energy Switzerland LTD |
ZP-2021-002-02 Rev.01 |
Gas-insulated metal-enclosed combined disconnector / earthing switch |
ELK-3, 420 kV, TK3 |
Hitachi Energy Switzerland LTD |
ZP-2021-002-03 |
Gas-insulated metal-enclosed earthing switch with short-circuit making current capability |
ELK-3, 420 kV, EB3 |
Hitachi Energy Switzerland LTD |
ZP-2021-004-01 Rev.01 |
Metal enclosed gas-insulated switchgear with vacuum circuit-breaker, combined function earthing switch and solid insulated busbar connection |
PrimeGear ZX0, feeder panel, width 500 mm with VD4S0 12.12.25 and 3PS |
ABB India Ltd / Nashik |
ZP-2021-004-02 |
Metal enclosed gas-insulated switchgear with vacuum circuit-breaker, combined function earthing switch and solid insulated busbar connection |
PrimeGear ZX0, feeder panel, width 500 mm with VD4X0 12.12.25 and 3PS |
ABB India Ltd / Nashik |
ZP-2021-004-03 Rev.01 |
Metal enclosed gas-insulated switchgear with vacuum circuit-breaker, combined function earthing switch and solid insulated busbar connection |
PrimeGear ZX0, feeder panel, width 500 mm with VD4X0 12.12.25 and 3PS |
ABB India Ltd / Nashik |
ZP-2022-002-01 |
420 kV Gas insulated metal-enclosed switchgear |
8DQ1 – 420 kV – 4000 / 5000 A – 63 kA – 50 Hz |
Siemens Energy Global GmbH & Co. KG / Berlin |
ZP-2022-003-01 |
145 kV Gas insulated metal-enclosed switchgear |
8DN8 – 145 kV – 3150 A – 40 kA – 50 Hz |
Siemens Energy Global GmbH & Co. KG / Berlin |
ZP-2022-004-01 |
245 kV Gas insulated metal-enclosed switchgear |
8DN9 – 245 kV – 3150 / 4000 A – 50 kA – 50 Hz |
Siemens Energy Global GmbH & Co. KG / Berlin |
ZP-2022-005-01 |
145 kV Gas insulated metal-enclosed switchgear |
8DN8-2 – 145 kV – 3150 A – 40 kA – 50 Hz Cable feeder with triple pole operated circuit-breaker |
Siemens Energy Global GmbH & Co. KG / Mülheim an der Ruhr |
ZP-2022-006-03 |
Metal-enclosed, SF6 insulated, medium-voltage switchgear, double bus-bar system, feeder panel composed of one functional unit and equipped with vacuum circuit-breaker, combined function earthing switch and disconnector |
ZX2, DBB, feeder panel, width 800 mm with vacuum circuit-breaker type VD4X 3612-31 (VG8K), combined function earthing switch UX2TE 12-31, disconnector UX2T 12-31 |
ABB s.r.o. / Brno |
ZP-2022-006-05 |
Metal-enclosed, SF6 insulated, medium-voltage switchgear, single bus-bar system, feeder panel composed of one functional unit and equipped with vacuum circuit-breaker, combined function earthing switch. |
ZX2, SBB1, feeder panel, width 800 mm with vacuum circuit-breaker type VD4X 3612-31 (VG8K) and combined function earthing switch UX2TE 12-31. |
ABB s.r.o. / Brno |
ZP-2022-006-07 |
Metal-enclosed, SF6 insulated, medium-voltage switchgear, single bus-bar system, feeder panel composed of one functional unit and equipped with vacuum circuit-breaker, combined function earthing switch. |
ZX2, SBB2, feeder panel, width 800 mm with vacuum circuit-breaker type VD4X 3612-31 (VG8K) and combined function earthing switch UX2TE 12-31. |
ABB s.r.o. / Brno |
ZP-2022-006-09 Rev.01 |
Metal-enclosed, SF6 insulated, medium-voltage switchgear, double bus-bar system, feeder panel composed of one functional unit and equipped with vacuum circuit-breaker, combined function earthing switch and disconnector. |
ZX2, DBB, feeder panel, width 800 mm with vacuum circuit-breaker type VD4X 3612-31 (VG6S), combined function earthing switch UX2TE 12-31, disconnector UX2T 12-31 |
ABB s.r.o. / Brno |
ZP-2022-006-10 Rev.01 |
Metal-enclosed, SF6 insulated, medium-voltage switchgear, single bus-bar system, feeder panel composed of one functional unit and equipped with vacuum circuit-breaker, combined function earthing switch |
ZX2, SBB1, feeder panel, width 800 mm with vacuum circuit-breaker type VD4X 3612-31 (VG6S) and combined function earthing switch UX2TE 12-31 |
ABB s.r.o. / Brno |
ZP-2022-006-11 Rev.01 |
Metal-enclosed, SF6 insulated, medium-voltage switchgear, single bus-bar system, feeder panel composed of one functional unit and equipped with vacuum circuit-breaker, combined function earthing switch |
ZX2, SBB2, feeder panel, width 800 mm with vacuum circuit-breaker (VG6S) type VD4X 3612-31 and combined function earthing switch UX2TE 12-31 Hersteller |
ABB s.r.o. / Brno |
